Product Details
Model Number: WS2812B-5050RGB-144D
Payment & Shipping Terms
Minimum Order Quantity: 100m
Delivery Time: 7-10 days
Payment Terms: EXW
Type: |
LED Flexible Strip |
HS Code: |
9405499000 |
Emitting Color: |
Full Color |
LED QTY: |
144LED/m |
Voltage: |
DC 5V |
Power: |
43.2W/m |
Length: |
5m/roll |
LED Size: |
SMD 5050 |
Board Width: |
12mm |
Signal Transmission Speed: |
800KHZ |
PWM: |
2KHZ |
Working Temperature: |
-20℃-60℃ |
Type: |
LED Flexible Strip |
HS Code: |
9405499000 |
Emitting Color: |
Full Color |
LED QTY: |
144LED/m |
Voltage: |
DC 5V |
Power: |
43.2W/m |
Length: |
5m/roll |
LED Size: |
SMD 5050 |
Board Width: |
12mm |
Signal Transmission Speed: |
800KHZ |
PWM: |
2KHZ |
Working Temperature: |
-20℃-60℃ |
Performance characteristics:
Popular in the Market: This product is highly sought after due to its consistent performance, reliable quality, and excellent cost-efficiency.
Efficient Signal Transmission: Utilizes a single signal line with a transmission speed of 800kHz and a PWM refresh rate of 2kHz, ensuring fast and accurate data communication.
Integrated IC for Enhanced Control: Each LED features a built-in IC, allowing for individual control of each pixel. This programmability enables a wide range of customizable lighting effects.
Technical Parameters:
| Type | Addressable LED Strip |
| Emitting Color | Full Color |
| Voltage | DC 5V |
| Total Length | 5m |
|
LED QTY |
144LED/m |
| Power | 43.2W/m |
| Length | 5m/roll |
| LED Size | SMD 5050 |
| Board Width | 12mm |
| Signal Transmission Speed | 800KHZ |
| PWM | 2KHZ |
| Warranty | 2 years |
Related Series:
| Model | Voltage | IC | LED QTY | Power | Total Length | Board Width |
| WS2812B 5050RGB-30D | DC 5V | WS2812B | 30LED/m | 9W/m | 5m | 10mm |
|
WS2812B 5050RGB-60D |
DC 5V |
WS2812B
|
60LED/m |
18W/m |
5m |
10mm |
| WS2812B 5050RGB-72D |
DC 5V |
WS2812B
|
72LED/m |
21.6W/m |
5m |
12mm |
| WS2812B 5050RGB-96D |
DC 5V |
WS2812B
|
96LED/m |
28.8W/m |
5m |
12mm |
| WS2812B 5050RGB-144D |
DC 5V |
WS2812B |
144LED/m |
43.2W/m |
5m |
12mm |
Customization:
Support and Services:
FAQ:
Q1: What is the nature of your company, are you a manufacturer or a trading company?
A1: We proudly identify as a reputable LED module manufacturer, boasting a decade of experience in the LED industry.
Q2: What are the key features of your LED strip lights?
A2: Our LED string lights are known for their exceptional quality, energy efficiency, versatility, and long lifespan. They
provide a brilliant and cost-effective lighting solution for various applications.
Q3: Is there a minimum order quantity (MOQ) for LED strip lights?
A3: Yes, we typically have a minimum order quantity (MOQ) for our LED strip lights. The specific MOQ may vary depending
on the product model and type.
Q4: Can I request samples of your LED strip light before placing a larger order?
A4: Yes, we understand the importance of evaluating the product quality. We offer samples of select LED strip lights, with
the recipient responsible for the sample delivery charges.
Q5: How are LED strip lights shipped, and what is the expected delivery timeframe?
A5: Once payment is confirmed, we're committed to efficient order processing and timely delivery. Generally, LED strip
orders have a delivery lead time of 7-10 days post-payment confirmation. Express shipping takes approximately 5-7 days
to arrive by air.
Q6: Do you offer customization or personalized packaging for LED strip lights?
A6: Yes, we provide customization options to cater to your specific needs. Whether it's custom LED strip specifications,
color options, or personalized packaging, we are here to accommodate your requirements.
